Diamond Saw Blades

1. Cold Press Sintering of High-Purity Diamond Particles

Using 60/80 mesh selected high-purity diamond particles, they are cold-pressed and sintered at 800°C. The holding force of the particles is 35% higher than that of ordinary saw blades. During cutting, the teeth are less likely to fall off, and the sharp cutting edge can be maintained for 20 consecutive hours.

2. Thickened and Shock-Resisting Steel Base Design

Using a 2.0mm thick 65Mn shock-resisting steel base, it undergoes secondary tempering to relieve stress. During cutting, the radial deviation is less than 0.1mm, avoiding the problem of jitter and edge breakage during high-speed operation.

3. Narrow Blade Head Slot Structure

The blade head is equipped with 3 evenly distributed narrow slot for chip removal. The cuttings generated during cutting can be quickly discharged, avoiding the problem of chips getting stuck between the saw blade and the material, and reducing the number of stoppages for cleaning during the operation.


1. Cutting Tiles for Home Decoration

When cutting floor tiles in the living room or kitchen wall tiles in daily home decoration, this saw blade cuts the tiles with a smooth cutting edge. There is no need for secondary grinding and they can be directly laid, meeting the requirements of environmental protection and low noise in home decoration construction. It will not cause a large amount of dust pollution to the indoor environment.

2. Repairing Stone Walkways in Residential Areas

When property management or construction teams repair granite walkways and curb stones in residential areas, it can quickly cut the excess stone edges, with a neat cutting edge and no situation of stone splashing. It complies with the safety operation specifications for small-scale outdoor municipal projects.

3. Cutting Stone for Small Hardware Stores

When offline hardware stores cut small-sized quartz stone countertops and cement prefabricated plates for customers, this saw blade cuts quickly, without causing dark cracks in the plates, reducing material loss in the store and improving processing efficiency.



1. Adjusting Blade Head Size as Per User's Requirements

We can customize the width of the blade head within the range of 1.2-3.0mm based on the thickness of the cutting materials commonly used by users. Without the need for users to replace the equipment, it can adapt to their regular operation needs. This rapid adjustment is achieved through our own sintering mold workshop, and most competitors cannot complete small-batch customization within 3 days.

2. Exclusive Adaptation of Diamond Concentration

For the soft/hard materials commonly cut by users, we can adjust the concentration ratio of diamond particles to avoid waste of particles when cutting soft materials and avoid wear when cutting hard materials. This customization requires our technical team to conduct material matching tests in advance. This is an exclusive service that ordinary contract factories do not have.

3. Non-standard Processing of Installation Hole Positions

If the user's old equipment has special installation hole position requirements, we can directly complete non-standard hole processing on the base. Users can install and use it directly after receiving it, without having to find a store for secondary hole expansion, saving operation preparation time.


Parameter	Specification
Product Name	Diamond Saw Blades
Blade Type	Segmented Diamond Blade / Continuous Rim Blade / Turbo Diamond Blade
Cutting Material	Synthetic Diamond Grit + Metal Bond Matrix
Core Material	High Strength Steel Core
Diamond Concentration	Customized according to cutting application
Bond Type	Metal Bond (Cobalt, Copper, Iron, Nickel-based options)
Blade Diameter	4" – 70" (100 mm – 1800 mm), Custom sizes available
Segment Height	10 mm – 20 mm (Standard), Custom available
Segment Width	2.8 mm – 7.0 mm
Core Thickness	1.5 mm – 5.0 mm
Arbor Hole Size	20 mm / 22.23 mm / 25.4 mm / 50 mm / Custom
Diamond Grit Size	30/40, 40/50, 50/60, 60/80 Mesh (Customized)
Welding Method	Laser Welding / High Frequency Welding / Silver Brazing
Cutting Method	Wet Cutting / Dry Cutting
Maximum Operating Speed	25–55 m/s (depending on blade size and application)
