Pure Titanium

1.Excellent Corrosion Resistance

Titanium naturally forms a stable and self-healing oxide film on its surface. This passive layer protects the metal from many chloride-containing and chemically aggressive environments, making it a practical choice for chemical processing, seawater systems, and heat-exchange equipment.

2.Grade-Based Material Selection

China Super Tech does not treat all commercially pure titanium as the same material. Grades such as Grade 1, Grade 2, Grade 3, and Grade 4 have different strength and formability characteristics. We select the grade according to the required strength, forming process, corrosion environment, and final component requirements rather than simply supplying a standard grade.

3.Controlled Manufacturing Process

Our production process can integrate material preparation, forming, machining, heat treatment, and surface treatment according to the product design. This reduces the risk of dimensional variation and inconsistent material performance when customers otherwise have to coordinate multiple suppliers.

4.Reliable Material Traceability

Material composition and mechanical properties can be verified against the applicable material standard, with inspection documentation available according to order requirements. This is important for industrial equipment where material substitution or uncontrolled chemical composition can affect service life.

5.Lightweight Without Sacrificing Corrosion Performance

Titanium has a density of approximately 4.5 g/cm³, significantly lower than stainless steel. For equipment where corrosion resistance and weight both matter, titanium can reduce component weight while maintaining the required structural performance.

1.Chemical Processing Equipment

Titanium is commonly considered for heat exchangers, tanks, piping components, and other equipment exposed to corrosive chemicals. Its stable oxide film provides protection in many oxidizing and chloride-containing environments, helping reduce corrosion-related maintenance.

2.Seawater and Desalination Equipment

For seawater intake systems, desalination equipment, and related heat-transfer components, titanium is useful because seawater contains a high concentration of chloride ions that can cause localized corrosion in many conventional metals. Titanium's passive oxide layer provides strong resistance to this environment.

3.Heat Exchangers

Titanium tubes and components are suitable for heat exchangers where the process fluid is corrosive or contains seawater. Its corrosion resistance can help extend service intervals and reduce the risk of tube leakage caused by corrosion.

4.Chlor-Alkali and Chemical Equipment

Certain chemical processes involve chloride-containing media that place demanding requirements on equipment materials. Properly selected titanium grades can provide a corrosion-resistant material option while maintaining good fabricability for industrial components.

5.Medical and General Industrial Components

Commercially pure titanium can also be used for selected medical, laboratory, and industrial components where low density, corrosion resistance, and biocompatibility-related material requirements are important. The exact grade and applicable certification should be confirmed according to the end-use requirements.

1.Grade Selection Based on Actual Working Conditions

China Super Tech can help customers select between different commercially pure titanium grades based on the operating medium, temperature, required strength, forming requirements, and applicable standard. This prevents customers from paying for a higher-strength grade when it is not necessary or selecting a grade that is difficult to form.

2.Integrated Processing

Instead of supplying only raw material, we can coordinate cutting, forming, CNC machining, welding, heat treatment, and surface finishing according to the component design. This is particularly useful for customers who need finished titanium parts rather than standard stock.

3.Drawing-Based Manufacturing

Customers can provide drawings, dimensions, tolerances, material grades, and surface requirements. Our manufacturing process can then be organized around the actual component rather than forcing the design to fit an existing standard product.

4.Inspection and Documentation

For industrial orders, material certificates and inspection records can be arranged according to the agreed specification. Chemical composition, mechanical properties, dimensions, and surface condition can be checked against the applicable requirements before shipment.

Parameter	Specification
Material	Commercially Pure Titanium
Available Grades	Grade 1, Grade 2, Grade 3, Grade 4
Common Grade	Grade 2
Typical Standards	ASTM B265, ASTM B348, ASTM B381
Forms	Sheet, Plate, Bar, Rod, Tube, Wire, Forged Parts
Density	Approx. 4.5 g/cm³
Surface	Mill, Pickled, Polished, Machined or Customized
Manufacturing	Cutting, Forming, CNC Machining, Welding, Heat Treatment
Inspection	Chemical Composition, Mechanical Properties, Dimensional Inspection
Customization	Grade, Size, Shape, Tolerance, Surface and Packaging
